Summary of acceptance requirements for X-ray equipment in Vietnam

21:15, 10/07/2024

The Ministry of Science and Technology of Vietnam issued Circular 28/2015/TT-BKHCN on the promulgation of the "National Technical Regulation on General X-ray Equipment Used in Medicine" on December 30, 2015. In this Circular, regulations on the acceptance requirements for X-ray equipment are provided.

According to Circular 28/2015/TT-BKHCN, X-ray equipment and the related accessories for using the equipment must meet the requirements specified in the following table:

T	Inspection Parameter	Acceptance Requirement
I	Visual Inspection
1
	kVp Repeatability	The maximum deviation between the measured peak voltage value and the average value of the measurements with the same settings must be within ± 5%.
III	Exposure Time
1	Exposure Time Accuracy (Not applicable for X-ray equipment with only mAs settings)	The deviation of the measured value from the set value must be within ± 20% for the set exposure time greater than or equal to 100 ms and ± 30% for the set exposure time less than 100 ms.
IV	Output Dose
1	Output Dose Repeatability	The deviation between the maximum and minimum measured dose values at the same settings compared to the average value must be within ± 20%.
2	Output Dose Linearity	The linearity must be within ± 20%.
V	Focal Spot, Beam Characteristics, and Beam Filtering
1	Effective Focal Spot Size	The variation of the focal spot must not exceed the allowable range.
2	Beam Collimation Accuracy	The collimation deviation must not exceed 1.50
3	Congruence between Light Field and Radiation Field	The deviation of one edge between the two fields must not exceed 2%, the total deviation of two edges along each axis must not exceed 3%, and the total deviation of the edges along both axes must not exceed 4% of the distance from the focal spot to the image receptor.
4	Primary Beam Filtration	HVL must not be lower than the minimum allowable value.

For detailed information, refer to Circular 28/2015/TT-BKHCN, effective from June 1, 2016.
